Wood Logs Chipper
Introduction:
1. Processing log diameter : 50-300mm
2. End chips size :20-40mm
3. Production capacity : 7-15tons/hour
4. We can also do production line design as customer needs
Technical Data
| Model | SH216 | SH218 |
| Feeding Inlet | 240*540mm | 310*680mm |
| Rotor Diameter | 650mm | 800mm |
| Blade Quantity | 2 or 3 | 2 or 3 |
| Motor Power | 55KW | 110KW |
| In Feed Conveyor | 6000mm | 6000mm |
| Out Feed Conveyor | 10000mm | 10000mm |
| Capacity | 7-10T/H | 9-13T/H |
| Weight | 4070KG | 7500KG |
Related Products:
| Disc Wood Chipper Machine | |
| Specification | SHJP1600 |
| Feeding inlet size | 450*450mm |
| Knife No. | 6片 |
| Main motor power | 185kw |
| Horizontal feed conveyor | 8000mm |
| Slope outfeed conveyor | 10000mm |
| Wood chipper size | 20-35mm |
| Discharging type | down |
| Production capacity | 25-30t/h |
Wood Composite Crusher
| Model | SH2000-1000 | SH1300-600 | SH1400-600 | SH1600-600 | |
| Feeding inlet size | 2000x1000mm | 1250x600mm | 1400x600mm | 1600x600mm | |
| Blade roller diameter | 1400mm | 850mm | 850mm | 850mm | |
| Blade roller speed | 750RPM | 850RPM | 850RPM | 850RPM | |
| Production capacity | 70-100ton/H | 12-15ton/H | 18-20ton/H | 25-30ton/H | |
| 1 | YG8 hammer blade qty | 86pcs | 20pcs | 24pcs | 28pcs |
| 2 | Blade qty | 3groups/9tablets | 2groups/4tablets | 2groups/4tablets | 2groups/4tablets |
| Max. Processing log diameter | <800mm | 450mm | 450mm | 450mm | |
| Main motor power | 450kw | 160kw | 200kw | 250kw | |
| Wood chipper size | 3-5cm | 2-4cm | 2-4cm | 2-4cm | |
| Working life of blades | 4000T-5000T | 4000T-6000T | 4000T-6000T | 4000T-6000T | |
|
Optional :
|
|||||
Image of Electrical type
Image of Diesel engine type
STUMP CRUSHER
1.Indtroduction:
2.Specification:
| Technical data | Model SH3600-1600 |
| Blade shaft size | 1600x850mm |
| Rotor diameter | 800mm |
| Blade quantity | 4 |
| Main motor power | 185KW |
| Feeding inlet diameter | 3600mm |
| Out feed conveyor | 12meters |
| Capacity | 25-30Ton/Hour |
| Weight | 18000kg |
3.Photos:
