Ring type log debarker Mobile wood peeling machine ,Single roll Wood Debarking Machine
Ring Type Log Debarker
| Model | SHHB220 | SHHB260 | SHHB320 |
| Blade Disk Diameter | 560MM | 560MM | 560MM |
| Blade Quantity | 4 | 4 | 4 |
| Log Diameter | 60-220MM | 100-260MM | 150-320MM |
| Feeding Speed M/MIN | 8.3 | 8.3 | 8.3 |
| Debarking Rate | 98% | 98% | 98% |
| Motor Power | 6.2KW | 6.2KW | 6.2KW |
Single Roll Log Debarker
| Model | SHBP6000 | SHBP9000 |
| Capacity Ton/Hour | 5-10 | 10-15 |
| Motor Power | 37KW | 45KW |
| Log Diameter | 15-320mm | 15-320mm |
| Debarking Rate | 98% | 98% |
| Max Log Length | 6000mm | 9000mm |
| Weight | 4 | 5 |
Double Rolls Log Debarker
| Model | SHBPD4500 | SHBPD6000 | SHBPD9000 |
| Capacity TON/HOUR | 3-6 | 5-10 | 10-15 |
| Motor Power | 7.5kw*2 | 11*2 | 15*2 |
| Log Diameter | 50-250mm | 50-250mm | 50-250mm |
| Debarking Rate | 98% | 98% | 98% |
| Max Log Length | 4500mm | 6000mm | 9000mm |
| Overall Size | 5.8*1.6*2 | 7.5*1.6*2 | 11*1.6*2 |
| Weight | 4 | 4 | 5 |
