China Made Vertical Saw Mill, Timber sawing vertical band saw sawmill machine with trolley
Vertical Band Saw with Carriage -With Foundation
1.Easy usage, no need to build working foundation .
2.Complete body transport, no nee installation .
3.Max. sawing wood diameter/width: 600mm
4.Max. sawing wood length: 6meters
5.Saw walking forward/back: Electric walking
Specifications:
| Technical data | MJ329-M3000 | MJ329-M5000 |
| Saw wheel diameter | 900mm | 900mm |
| Maximum sawing log diameter | 600mm | 600mm |
| Maximum sawing log length | 4meters | 6meters |
| Main motor | 18.5KW | 18.5KW |
| Carriage clip stake quantity | 3sets | 4sets |
| Carriage running wheel quantity | 2sets | 3sets |
| Carriage walking/advance | Electric | Electric |
| Setting sawn size | Electric | CNC |
| Log clamping mode | Electric | Electric |
| Rail length | 11meters | 15meters |
| Weight | 4000kgs | 5500kgs |
MJ3212 &MJ3212B Vertical Band Sawmill With CNC Log Carriage
This lathe is mainly used to Vertical cut or slab-cut logs of a large or middle diameter or re-saw timbers into slabs and square logs of various specifications and it smoothly runs at a high efficiency.In combination with carriage, it will enlarge the working range and improve product quality and hence is the ideal equipment for wood working enterprises.
1.MJ3212 CNC vertical band sawmill with automatic log carriage
| Technical data | MJ3212-ZD3000 | MJ3212-ZD5000 |
| Saw wheel diameter | 1250mm | 1250mm |
| Maximum sawing log diameter | 1200mm | 1200mm |
| Maximum sawing log length | 4meters | 6meters |
| Main motor | 37KW | 37KW |
| Saw blade L*W*T | 8600x150x1.25mm | 8600x150x1.25mm |
| Carriage clip stake quantity | 3sets | 4sets |
| Wood grasp mode | Electric | Electric |
| Carriage walking/advance | Frequency converter | Frequency converter |
| Setting sawn size | PLC touching screen | PLC touching screen |
| Carriage length | 3meters | 5meters |
| Rail length | 10meters | 18meters |
| Weight | 7500kgs | 8000kgs |
2. MJ3212B Vertical Band Saw with CNC Automatic Log Carriage
| Technical data | MJ3212B-ZD3000 | MJ3212B-ZD5000 |
| Saw wheel diameter | 1250mm | 1250mm |
| Maximum sawing log diameter | 1500mm | 1500mm |
| Maximum sawing log length | 4meters | 6meters |
| Main motor | 45KW | 45KW |
| Saw blade L*W*T | 9200x150x1.25mm | 9200x150x1.25mm |
| Carriage clip stake quantity | 3sets | 4sets |
| Wood grasp mode | Electric | Electric |
| Carriage walking/advance | Frequency converter | Frequency converter |
| Setting sawn size | PLC touching screen | PLC touching screen |
| Carriage length | 3meters | 5meters |
| Rail length | 10meters | 18meters |
| Weight | 11000kgs | 12000kgs |
Optional part : hydraulic chain log turner
Feedback from Users
Optional part : Log loading deck
